TECHNICAL SPECIFICATIONS


Since our foundation, we’ve been at the forefront of valve technology. We know from experience that our first-generation Smart Valves, while efficient and reliable, are no longer the leading edge in Smart Valve design. That’s why trusting advice about Smart Valves from anyone other than experts like us is ill-advised. Only a qualified source can provide you with the information necessary to make an informed decision.

NSF Certifications

Screen Shot 2022-10-21 at 11.30.34 AM.png
Screen Shot 2022-10-21 at 11.37.03 AM.png

Customized Specifications

Each SMART VALVE™ is built to exacting specifications based on the specific water system parameters. Spring tension is calibrated based on the users’ pressure and flow profile. Connection types are determined by the existing pipe configuration. A completed site survey is required for all orders.

Construction
The SMART VALVE™ is made primarily of Acetron GP, an extremely strong, self-lubricating space-age resin created by Quadrants. Acetron GP is the material of choice when precision parts are required for impact and wear resistance in a wide range of industrial and mechanical applications.  With low, consistent internal stress, this material experiences little dimensional change during use. Acetron GP is also an ideal material for use in wet environments because it resists moisture, will not accumulate particulates, will not corrode and self-seals extremely well eliminating the need for seals and gaskets that would wear out, making Acetron GP the ideal choice for the SMART VALVE. All non- Acetron GP components are manufactured from food-grade stainless steel.

Configurations
The SMART VALVE™ is available in the following standard plumbing sizes: 5/8” 3/4” 1” 1.5” 2” 3” 4” 6” 8” 10” 12” Larger sizes available on a custom order.

Specifications

  • Valve body, plunger, backplate: Acetron GP

  • Shaft, spring: Food-grade Stainless Steel

  • For dimensions of common sizes please see our Cut Sheets.

Cut Sheets

* Click in each cut sheets to download its file.

0.75 inch cut sheet SV2G                                        1 inch cut sheet SV2G

1.5 inch cut sheet SV2G                                          2 inch cut sheet SV2G

3 inch cut sheet SV2G                                             4 inch cut sheet SV2G

6 inch cut sheet SV2G                                             8 inch cut sheet SV2G

10 inch cut sheet SV2G                                           12 inch cut sheet SV2G

Installation

* Click in each type of installation to download its file for instructions.

Installation Instructions SV2G-FLANGED        Installation Instructions SV2G-THREADED

The SMART VALVE™ is installed on the USER side of the water meter. The valve is made in flanged and threaded configurations according to your system pipe design. Installation of the SMART VALVE™ should be performed by a licensed plumber and any plumber can easily install the unit. All installations should include gaskets on flanged units or pipe tape on threaded units to prevent water leakage. Please see our detailed Installation Instructions for Flanged or Threaded pipe.
